COMING SOON - INTEGRIX IX6 3-18X44 34MM FFP MID POWER SCOPE, A2 MOA
Regular price
$1,599.97 USD
Sale price
$1,599.97 USD
Regular price
Save 0
Sold out
***COMING SOON***
THE CULMINATION OF INTEGRATED & INTELLIGENT OPTICAL DESIGN & MANUFACTURING.
INTEGRIX is pinnacle performance. Years of experience were brought to the forefront through expert development and evaluation, countless testing, and meticulous manufacturing. German and Japanese glass lenses used exclusively in every INTEGRIX optic are individually centration tested, multi-coated for glare, reflection, and scratch resistance, and upon assembly are inspected for concentricity as a whole.
THE END RESULT? Optimized image quality with over 92% light transmission, edge-to-edge sharpness, minute distortion, and high contrast resolution.
DETAILS
- Individually Centration Tested German and Japanese Glass Lenses, Concentric Tested Post Assembly
- Multi-Coated Lenses for Glare, Reflection, and Scratch Resistance
- Low Aberration Optimized Image Quality with Over a 92% Light Transmission
- Edge to Edge Sharpness, High Contrast, and High-Resolution Standard
- Reliable Adverse Temperature and Environmental Performance with -40° to 160° Fahrenheit Operational Range and IPX7 Waterproof Rating
- Rated, at Minimum, for .338 LAPUA Magnum
- Red and Green Reticle Illumination with 8 Brightness Intensity Settings
- 12 Hour Automatic Shutoff
- Side Adjustable Parallax Turret Smoothly and Accurately Adjusts from 30 Yards / 27.4 m to Infinity
- Intuitive Lockable and Zero Resettable Windage and Elevation Turrets, Serrated and Oversized for Glove Use
- Elevation Turret Equipped with Zero Stop
- Serrated Power Ring and Rear Adjustable Eyepiece Diopter
- Make Transitioning Across Magnification Range Effortless with Included Oversized Throw Lever
ETCHED GLASS A2 MOA RETICLE
Clutter-free at both low and high magnifications to supplement overall FOV qualities, the German Duplex inspired A2 MOA reticle features sub-tensions that transition from being bolded to see-through while tapering down to a fine point towards the reticle’s center. The center crosshair, at low magnification, provides a quick-to-acquire T-Dot and fully illuminates.
The T-Dot at higher magnification opens up and provides an unobtrusive 0.5 MOA floating center dot which focuses the eyes to the center of the reticle and frees up space between it and the remainder of the reticle to provide a better view of critical target details. The reticle spans 10 MOA up and 60 MOA down and 30 MOA left and right in 1 MOA increments.
LOW POWER
HIGH POWER
RETICAL BREAKDOWN
SPECIFICATIONS
| MADE IN USA | No |
|---|---|
| WARRANTY | Lifetime |
| MATERIALS | 6061-T6 Aluminum |
| COLOR(S) | Black |
| SURFACE FINISH | Anodized |
| PARTS INCLUDED | 0 |
| FOCAL PLANE | FFP (First Focal Plane) |
| RETICLE | A2 MOA |
| RETICLE TYPE | Etched Glass |
| RETICLE ILLUMINATION | Yes |
| RETICLE COLOR(S) | Red and Green |
| ILLUMINATION TOGGLE TYPE | Button |
| BRIGHTNESS SETTINGS | 8 |
| BRIGHTNESS MODE(S) | Manual |
| WATERPROOF RATING | IPX7 |
| OPERATING TEMPERATURE HIGH (⁰F) | 160 |
| OPERATING TEMPERATURE LOW (⁰F) | -40 |
| OPERATING TEMPERATURE HIGH (⁰C) | 70 |
| OPERATING TEMPERATURE LOW (⁰C) | -40 |
| BALLISTIC DROP COMPENSATION | No |
| RANGE ESTIMATION | Yes |
| BATTERY LOADING | Left Side Turret |
| BATTERY TYPE | CR2032 3V |
| CLICK VALUE @ 100 YARDS (MOA) | 1/4 |
| WINDAGE ADJUSTMENT LEFT (MOA) | 12 |
| WINDAGE ADJUSTMENT RIGHT (MOA) | 12 |
| TOTAL WINDAGE (MOA) | 24 |
| ELEVATION ADJUSTMENT UP (MOA) | 60 |
| ELEVATION ADJUSTMENT DOWN (MOA) | 30 |
| TOTAL ELEVATION (MOA) | 90 |
| MAGNIFICATION MAX. | 18 |
| MAGNIFICATION MIN. | 3 |
| ANGULAR FOV LOW MAG. (DEGREES) | 7.2 |
| ANGULAR FOV HIGH MAG. (DEGREES) | 1.2 |
| LINEAR FOV LOW MAG. (FT @ 100 YDS) | 37.7 |
| LINEAR FOV HIGH MAG. (FT @ 100 YDS) | 6.3 |
| LINEAR FOV LOW MAG. (M @ 100 M) | 12.6 |
| LINEAR FOV HIGH MAG. (M @ 100 M) | 2.1 |
| LIGHT TRANSMISSION (%) | 92% |
| EYE RELIEF (IN) | 3.94 |
| EYE RELIEF (MM) | 100 |
| PARALLAX CONTROL | Left Side Adjustable Turret |
| PARALLAX MAX (YDS) | Infinity |
| PARALLAX MAX (M) | Infinity |
| PARALLAX MIN (YDS) | 30 |
| PARALLAX MIN (M) | 27.4 |
| EXIT PUPIL HIGH MAG. (MM) | 2.5 |
| EXIT PUPIL LOW MAG. (MM) | 11 |
| OBJECTIVE LENS DIAMETER (MM) | 44 |
| DIOPTER ADJUSTMENT | -3D ~ +2D |
| DIOPTER TYPE | Friction Secured |
| CALIBER RATING | .338 Lapua Magnum |
| WEIGHT (OZ) | 29.7 |
| WEIGHT (G) | 841 |
DIMENSIONS
| EYEPIECE LENGTH (IN) | 3.5 |
|---|---|
| EYEPIECE LENGTH (MM) | 88 |
| FRONT MOUNTING SPACE (IN) | 1.77 |
| FRONT MOUNTING SPACE (MM) | 45 |
| LENGTH (IN) | 11.9 |
| MAINTUBE DIAMETER (MM/IN) | 34 mm |
| OBJECTIVE LENGTH (IN) | 3.2 |
| OBJECTIVE LENGTH (MM) | 80 |
| OUTER EYEPIECE DIAMETER (IN) | 1.81 |
| OUTER EYEPIECE DIAMETER (MM) | 46 |
| OUTER OBJECTIVE BELL DIAMETER (IN) | 2.09 |
| OUTER OBJECTIVE BELL DIAMETER (MM) | 53 |
| REAR MOUNTING SPACE (IN) | 1.85 |
| REAR MOUNTING SPACE (MM) | 47 |
ACCESSORIES INCLUDED
Throw LeverFlip-open Lens Caps
Hex Wrench 2 mm
Hex Wrench 1.5 mm
CR2032 Battery
Cleaning Cloth
